| Brand Name : | YASEN |
| Model Number : | SXT-150,200,300,500,700,1000F |
| Certification : | CE,ISO9001:2008 |
| Supply Ability : | 100 Set/Sets per Month industrial washing machines for sale |
| Price : | $2,500.00/sets >=1 sets |
Use:
SXT-F Series Washer-extractor is suitable for hotel,restaurant,hospital,garment factory,
industry-mining enterprise as well as individual washing-dyeing.It is used for washing
cotton,wool,woolen,chemical fiber and other fabrics.
Short introduction:
Full-automatic control by computer control system
l SXT-F washer-extractor has professional computer control system,excellent capacity and super function ,it contains 30 programmable procedures and 5 standard programs, and all design is near to human feature.
l User can control work liquid-level,wash temperature ,wash time,and efficiently satisfy with wash request in different situations.
High strength,long durability
l Creative structure from drum design of excellent stainless steel ensures that machine lifespan is prolonged during overload situation.
l Adopting advanced limit principle to design outer vat is made by stainless steel(50-150 kg),it can resist corrosion and have high stability.
l Different design of high-strength big shaft-pedestal and high-accuracy short shaft can effectively reduce transverse vibration moment .Bearing of major shaft adopt high accurate core,so that prolong use lifespan and durability.
l Seal technology of major shaft have acquired state invention patent,double design of water-proof,imported seal material of fluorine rubber,special compartment design,assuring that protect bearing and improve use lifespan.
Leading slight vibration of industry washer
l Because of scientifically adding overload weight at the front of suspended object,gravity of suspended object and center of vibration source can combine in working state,so that reach perfect balance of suspended object.
l Spring of vibrationproof effciency and effective vibration-reducing rate to 98%.
Excellent design and fine production
l Frequency-conversion drives,endless speed adjusting stable,quiet rum.
l High-quality bearing,long lifespan.
l Imported seal material of major shaft ,patent technology design ,effectively resists high temperature and super acid-alkali.
l Stainless steel panel,high corrosion proof(back panel is galvanization).
l Safe door-lock union devise of patent technology ensure safety.
l Five compartment automatic detergent adding system,injection moulding structure of nylon combination,high corrosion proof.
l Larger diameter loading door and human design conveniently load and unload,so reduces labor strength.
l Adopting steam heating,hot water heating.
Product Parameters:
Name: Automatic Industrial Washer-Extractor | |||||||
SXT Series | Model | ||||||
Attributes | SXT-150F | SXT-200F | SXT-300F | SXT-500F | SXT-700F | SXT-1000F | SXT-1500F |
Rated Capacity(g) | 15 | 20 | 30 | 50 | 70 | 100 | 150 |
Drum Dimension(mm) | Φ636×472 | Φ730×450 | Φ900×470 | Φ970×650 | Φ1200×620 | Φ1200×888 | Φ1470×880 |
Washing Speed(r/min) | 42 | 42 | 40 | 50 | 35 | 35 | 30 |
Extracting Speed(r/min) | 850 | 800 | 770 | 740 | 670 | 670 | 610 |
Rated Voltage(V) | 220/380 /415 | 220/380 /415 | 220/380 /415 | 220/380 /415 | 220/380 /415 | 220/380/415 | 220/380/415 |
Motor Power(kw) | 1.5 | 2.2 | 3 | 4 | 7.5 | 7.5 | 15 |
Water Inlet(lnch) | G3/4" | G1" | G1" | G1.5" | G1.5" | G1.5" | G2" |
Steam lnlet(lnch) | G1/2" | G1/2" | G3/4" | G1" | G1" | G1" | G1.5" |
Electric Heating Power(kw) | 9 | 18 | 27 | 36 | 54 | 72 | - |
Steam Pressure(Mpa) | 0.3-0.5 | 0.3-0.5 | 0.3-0.5 | 0.3-0.5 | 0.3-0.5 | 0.3-0.5 | 0.3-0.5 |
Consumes Proportion of Steam(kg/kg) | 0.5 | 0.5 | 0.5 | 0.5 | 0.5 | 0.5 | 0.5 |
Drainage Dimension(mm) | Φ60 | Φ60 | Φ80 | Φ90 | Φ127 | Φ127 | Φ127x2 |
Air Pressure(Mpa) | 0.4-0.6 | 0.4-0.6 | 0.4-0.6 | 0.4-0.6 | 0.4-0.6 | 0.4-0.6 | 0.4-0.6 |
Noise dB(A) | <78 | <78 | <78 | <78 | <78 | <78 | <78 |
Dimension WxDxH(mm) | 1200x1060 x1230 | 1025x1000 x1400 | 1340x1380 x1700 | 1570*1455 *1780 | 1750x1800 x1980 | 1920*2150 *1990 | 2150×2420 ×2350 |
N.W.(kg) | 520 | 680 | 1500 | 2200 | 2800 | 3200 | 5500 |
|
|
